P10mm Indoor LED display Screen
P10mm Indoor LED display Screen
  • P10mm Indoor LED display Screen
  • Item : P10
  • Brand : OEM
Product Description
P10mm Indoor LED display is not so high as of P6mm and P7.62mm. It is very suitable to make big size led display. P10mm would not show a very good quality video if the led display size smaller than 2.56m x 1.92m.

Specification:

Pixel pitch: 10 mm
Pixel Density: 10,000 pixels/m2
LED Type: SMD 3-in-1
Pixels Configuration: 1R1G1B
Module Dimension: (LxH)160*160mm
Module Resolution: (LxH)16*16pixels
Cabinet Dimension: (LxHxW)640*640mm
Cabinet Resolution: (LxH)64*48pixels
Brightness Density: 1200 cd/m2
Display Color: 68.7 billion
Gray scale: 4096 gray scale in each Red、Green、Blue color
Viewing angle: Horizontal angle: 120 degree; Vertical angle: 120 degree
Drive mode: 1/4
Best Viewing distance: 12m
Average power consumption: 320W/M2
Max power consumption: 800W/M2
Working Voltage: AC220V15%, 47~64HZ
Refresh Velocity: ≧60 frame/sec
Refresh Rate: ≧300HZ
Effective Control Distance: 100m (KAT5 cable) /1000m or more (Optical fiber)
Signal Input: Composite,S-video,Component,VGA,DVI,HDMI,SDI,HD_SDI,etc
Controlling system: PCTV non-linear editting card DVI display card main controller card optical fiber transmission (Optional)
Effective Control Distance: 100m (KAT5 cable) /1000m or more (Optical fiber)
Lifespan: 100,000 Hours
Ingress Protection: Front IP40, Rear IP30
MTBF (Ave No Faliure Time): 10,000 Hours
Blind Pixels Rate: ≦0.0003
Operation temperature: - 30℃ ~ 60℃
Operation Humidity: 10% ~ 90% RH

Features:

Best consistency with signal input, vivid color
Best viewing angle 160 horizontal and 120 vertical
Centralized control management for multi-displays
≤0.5mm surface level up, smooth video
Flexible shape for large area
Easy transport,installation and maintenance
Energy-saving
High luminous efficacy
Modular design
Perfect quality and stability, 24*7 running
Standard cabinet, easy

Application:

PH10 indoor is mostly used for meeting room, stage,and TV show.
